Available units

Hydraulic systems

  • Reservoir
  • Pipe
  • Viscoelastic Pipe
  • Valves
  • Discrete Losses
  • Surge Tank, Surge Shaft, Surge Vessel
  • Air vessel
  • Cavitation Compliance with Mass Flow Gain Factor
  • Pressure Sources
  • Pumps
  • Francis Pump-Turbine
  • Pelton Turbine
  • Kaplan Turbine
  • Propeller Turbines

Electrical machines

  • Synchronous Machines (1~, 3~ or 6~)
  • Permanent magnet (3~)
  • Three-phase generalizedInduction
  • Machines (wound or squirrel cage rotor) 3~
  • Two-phase induction motor
  • DC motor
  • Mechanical mass
  • Stator mass
  • Clutch

Three-phase elements

  • Voltage supply
  • Transmission lines
  • Circuit-breaker
  • Phase shifting transformer
  • Three windings transformer
  • Load

Single-phase elements

  • Voltage supply
  • R-L-C impedance
  • Varistor
  • Circuit-breaker
  • Linked inductor
  • Transformer

Three-phase converters

  • Rectifier (diode)
  • Current converter (thyristor)
  • Voltage inverter (thyristor GTO or IGBT)
  • Current variator (thyristor)

Semiconductors

  • Diode
  • Thyristor
  • Thyristor GTO
  • Thyristor GTO + diode
  • Triac
  • IGBT + diode
  • IGBT

Analog function units

  • Program
  • S-transfer functions
  • Regulator
  • Logic table
  • Points function
  • External DLL

Digital function units

  • Averager
  • Sample
  • Limiter
  • Pulse generator
  • Z-transfer function
  • Hysteresis
  • on-line FFT
